When welding arc welding, attention must be paid to safety and protection. Safety and protection technologies mainly prevent electric shock, arc radiation, fire, explosion and toxic gases and soot poisoning.

1 to prevent electric shock

In the case of electrode arc welding, there is a risk of electric shock due to the grid voltage and the output voltage of the welder and the voltage of the portable lighting. Therefore, take measures to prevent electric shock. Or zero. Welding cables and welding tongs should be well insulated. If damaged, repair them in time. When welding electrode arc welding, wear insulated shoes and wear electric welding gloves. When welding in boilers, pressure vessels, pipes, and narrow wet trenches, there should be insulation mats and some people should be supervised. When using portable lighting, the voltage does not exceed the safe voltage of 36V, and does not exceed 12V when working at height. When working at heights, work within 5m of the high-voltage line or within 2.5m of the low-voltage line. Power must be cut off, and a warning sign should be placed on the switch to set up supervision. In case someone gets an electric shock, cut off the power quickly and rescue in time.

2 to prevent arc radiation

Strong arc and UV rays from the welding arc can damage the eyes and skin. When welding electrode arc welding, it is necessary to use a mask with arc welding goggles, wear overalls and wear electric welding gloves. When multi-person welding operation, it is necessary to pay attention to avoid mutual influence. It is advisable to set the arc protection screen or take other measures to avoid the cross-effect of arc radiation.

Isolated Mars. When there is strong wind above level 6, no effective safety measures can be taken for open-air welding operations and high-altitude operations. Fire-fighting facilities should be installed near the welding site. After the welding operation is completed, the brake should be opened and the site should be cleaned in time to completely eliminate the fire.

3 to prevent fire

In the welding operation source of less than 10m, below the aerial work and within the scope of welding Mars, organic dust, wood, wood chips, cotton yarn, straw mat, oil, gasoline, paint and other flammable materials should be thoroughly removed. If there are flammable materials that cannot be evacuated, such as wood, flammable materials that have not been removed and insulated, reliable safety measures should be taken, such as spraying with water, covering wet sacks, asbestos cloth, etc.

4 to prevent explosion

Within 10m of the welding operation point, there shall be no explosives. In the room with explosive mixed gas such as oil depot, oil room, acetylene station and spray booth, welding operation is strictly prohibited. Do not weld on pressure vessels and pipes with pressure inside without special measures. Before welding the container filled with inflammable and explosive materials, the contents should be exhausted and replaced with water, steam or nitrogen, and cleaned: the concentration of the gas medium is checked and analyzed with a measuring instrument such as a blasting instrument; When opening the lid, the operator must hide from the container orifice.

5 to prevent toxic gases and smoke poisoning

When welding arc welding, it will produce toxic gases such as soluble fluorine, hydrogen fluoride, manganese, nitrogen oxides and dust, which will lead to fluorine poisoning, manganese poisoning, electric welding dust and lungs, especially the alkaline welding rod is welded inside the container and pipeline. Therefore, it is necessary to take measures such as exhaust ventilation, partial ventilation, small electric welding and smoke exhausting units, etc. according to the specific conditions.
